B&R X20 DO 9322

Price 10000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

B&R X20 DO 9322 Specification

Shape
Rectangular

IP Rating
IP20

Humidity %
5% to 95%, non-condensing

Overheating Protection
Integrated

Connector Type
Plug-in terminal

Insulation Material
High-strength polymer

Mounting Type
DIN Rail Mount

Operating Temperature
-25C to +60C

Power Factor
Not applicable (DC module)

Efficiency
>95%

Surface Finish
Matte

Feature
Hot swap capability

Product Type
Digital Output Module

Application
Automation Systems, Industrial Control

Protection Level
Integrated short-circuit and overload protection

Frequency (MHz)
DC operation, not applicable

Rated Voltage
24 V DC

Energy Consumption
Max. 6 W

Output Type
Digital

Color
Black/Gray

Dimension (L*W*H)
99 x 36 x 55 mm

Weight
145 g

Size
Compact/module

Phase
Single Phase

Input Voltage
24 V DC

Connection Type
Spring clamp terminal

No Of Poles
16 digital outputs

Material
Industrial-grade plastic, metal contacts

Bus System
X20 system bus

Electrical Life
10^7 switching cycles

Residual Voltage
Max. 1.2 V

Response Time
< 0.5 ms

Channels
16 channels (positive switching)

Switching Current per Channel
Max. 0.5 A

Use Case
PLC, distributed I/O integration

Channel Grouping
2 groups of 8 digital outputs

Configuration
Software configurable

Galvanic Isolation
Yes, between channels and bus

Storage Temperature
-40°C to +85°C

Rated Current Total Output
Max. 8 A

Series
B&R X20

Status Indication
LED for each channel

Switching Voltage
24 V DC

B&R X20 DO 9322 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal, Letter of Credit (L/C), Days after Acceptance (DA), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Pieces Per Day

Delivery Time
1 Hours

Sample Available
Yes

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia

Main Domestic Market
All India

Certifications
B&R X20 DO 9322

About B&R X20 DO 9322

Experience commanding performance with the B&R X20 DO 9322 module, featuring 16 ace digital outputs, galvanic isolation, and hot swap capability for seamless operation. Secure instant savings when you buy this first-class automation solution, engineered for robust industrial control and distributed I/O integration. Each channel supports up to 0.5 A at 24 V DC with integrated protection, LED indication, and software configuration. Compact, efficient, and built for endurance, the B&R X20 DO 9322 is the optimal, reliable module-pick yours today for a competitive edge in automation.

Versatile Usage and Advanced Features

The B&R X20 DO 9322 is tailored for PLC and distributed I/O integration across automation systems. Its standout features-such as compact design, modular shape, spring clamp connection, and DIN rail mounting-permit swift installation. The hot swap capability and protective safeguards against overload, shorts, and overheating ensure resilience and uptime. Suitable for use in single-phase industrial control environments, this module excels in settings demanding high efficiency, reliability, and adaptability.

Export Market, Sample Policy, and Packaging Assurance

The B&R X20 DO 9322 is a preferred choice among Indian dealers, distributors, and global exporters due to its excellent outlay and performance. Our sample policy accommodates testing needs, and secure shipping methods guarantee safe transit. Each unit is meticulously packaged for protection during transit, and our quick dispatch process minimizes waiting. Whether you're a supplier or retailer, the B&R X20 DO 9322's assured quality and delivery makes it a wise investment for your industrial automation needs.

FAQ's of B&R X20 DO 9322:

Q: How does the B&R X20 DO 9322 ensure output safety and reliability?

A: The module features integrated short-circuit, overload, and overheating protection, along with galvanic isolation between channels and the system bus, ensuring safe and reliable performance in demanding automation environments.

Q: What are the primary applications of the B&R X20 DO 9322?

A: This module is designed for industrial automation systems, particularly PLCs and distributed I/O integration, where efficient and reliable control of digital outputs is essential.

Q: Where can I install the B&R X20 DO 9322 module?

A: It can be easily installed on a DIN rail within control panels thanks to its compact, modular form factor and spring clamp terminal connections, making it suitable for wide-ranging industrial setups.

Q: What makes the B&R X20 DO 9322 stand out for industrial use?

A: Its first-class features-including hot swap capability, LED status indication for every channel, high electrical life, and software-based configuration-provide flexibility, real-time monitoring, and ease of maintenance.

Q: How is the B&R X20 DO 9322 packaged and shipped?

A: Every unit is securely sealed in robust packaging materials to prevent damage during transit, and order fulfillment is expedited thanks to a quick dispatch process, ensuring rapid and safe delivery to customers.
