OMRON CJ1W-TC104

Get a Price/Quote

MOQ : 1 Piece

OMRON CJ1W-TC104 Specification

Overheating Protection
Yes, built-in error detection

Feature
High-speed input, Multi-type thermocouple support

Insulation Material
High-grade plastic

Mounting Type
DIN Rail mounting

Efficiency
High accuracy (<1C)

Humidity %
10% to 90% RH (non-condensing)

Connector Type
Removable terminal block

IP Rating
IP20

Shape
Rectangular

Operating Temperature
0 to 55C

Surface Finish
Matte

Product Type
Temperature Control Module

Application
For thermocouple temperature control in PLC systems

Protection Level
Standard electronic protection

Frequency (MHz)
50/60 Hz

Rated Voltage
24 V DC

Energy Consumption
Max. 4 W

Output Type
Relay Output

Color
Grey

Dimension (L*W*H)
90mm x 31mm x 65mm

Weight
Approx. 120g

Phase
Single Phase

Size
Unit size: standard CJ1 module

Input Voltage
24 V DC (power supply from PLC bus)

No Of Poles
4 Channel

Connection Type
Screw terminal

Material
Plastic

Resolution
0.1C

Sampling Period
250 ms total for all inputs

Insulation Resistance
20 M min. (at 500 VDC)

Compatible Thermocouple Types
K, J, T, E, R, S, B, N, L, U, W, Platinel II

Channels
4 channels (for thermocouple input)

Dielectric Strength
1,500 VAC for 1 min (between external terminals and ground)

Hot Swapping
Supported

Model Number
CJ1W-TC104

Control Method
ON/OFF, PID

OMRON CJ1W-TC104 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
OMRON CJ1W-TC104

About OMRON CJ1W-TC104

Introducing the remarkable OMRON CJ1W-TC104, a blue-ribbon choice for precise thermocouple temperature control in PLC systems. With astounding 0.1C resolution across 4 channels, this module supports multiple thermocouple types including K, J, and T for unbeatable versatility. Energy-efficient with a max. 4W consumption, it touts best-in-class features such as hot swapping, high-grade insulation, IP20 protection, and built-in overheating protection. Its robust plastic body, DIN rail mounting, and removable terminal blocks ensure seamless integration. Grab yours now at the best price for fresh, reliable performance, direct from Japan!

Primary Competitive Advantages & Suitability

The OMRON CJ1W-TC104 stands out due to its exceptional multi-type thermocouple support, high-speed input, and hot-swapping capabilities. This robust unit is widely used by industrial automation engineers, plant operators, and system integrators. It is ideally suited for use in PLC systems requiring accurate and reliable temperature control, making it perfect for sectors such as food processing, pharmaceuticals, and manufacturing where precision is paramount.

Sample Availability & Market Coverage

Samples of the OMRON CJ1W-TC104 are available upon request, with quick order processing for both domestic and international markets. As a leading dealer and exporter, we ensure thorough packaging for secure shipment, prioritizing the safe arrival of every unit. The device is suitable for all scales of operations, from SMEs to large enterprises, facilitating smooth shipment handling and broad market reach for discerning buyers worldwide.

FAQs of OMRON CJ1W-TC104:

Q: How does the OMRON CJ1W-TC104 help improve temperature control in PLC systems?

A: The OMRON CJ1W-TC104 offers precise temperature control with 0.1C resolution and multi-channel input, ensuring superior accuracy and efficiency in process management, reducing errors and enhancing product quality in automated environments.

Q: What thermocouple types are compatible with the CJ1W-TC104?

A: The unit supports a wide range of thermocouple types including K, J, T, E, R, S, B, N, L, U, W, and Platinel II, making it highly versatile for various industry needs.

Q: When should this module be considered for your PLC setup?

A: Use the CJ1W-TC104 when your application demands multi-point, high-accuracy temperature input and control, particularly in environments where hot-swapping, high-speed input, and robust insulation are required.

Q: Where is the OMRON CJ1W-TC104 typically used?

A: This module is commonly used in industrial automation, process industries, laboratories, and manufacturing plants, providing reliable temperature monitoring and control in critical operations.

Q: What is the process for ordering and receiving this module?

A: Simply contact your local or international dealer, place an order, and benefit from swift order processing and secure shipment. Packaging is designed to protect your device during transit for prompt and safe delivery.

Q: How does overheating protection and error detection work in this device?

A: The built-in overheating protection and error detection features automatically monitor the modules operation, promptly identifying and signaling faults to prevent damage or process interruptions.
