Price 1515 INR/ Piece

MOQ : 1 Piece

ALLEN-BRADLEY 1769-0F2 Specification

  • Efficiency
  • High System Efficiency
  • Feature
  • High Accuracy Output, Status Indicators
  • Operating Temperature
  • 0C to 60C
  • Surface Finish
  • Textured Plastic
  • Overheating Protection
  • YES
  • Insulation Material
  • Thermoplastic
  • Connector Type
  • Screw Terminals
  • Shape
  • Rectangular Module
  • Humidity %
  • 5% to 95% Non-condensing
  • IP Rating
  • IP20
  • Mounting Type
  • DIN Rail Mounting
  • Product Type
  • Analog Output Module
  • Application
  • Industrial Automation, PLC Systems
  • Protection Level
  • Overload and Short-Circuit Protection
  • Frequency (MHz)
  • 50/60 Hz (Rated) (not MHz)
  • Rated Voltage
  • 24V DC
  • Energy Consumption
  • Approx. 2.5W
  • Output Type
  • Analog (Current/Voltage)
  • Color
  • Light Grey/Yellow Module
  • Dimension (L*W*H)
  • 118 x 35 x 87 mm (Approx.)
  • Weight
  • Approx. 250 g
  • Size
  • Compact
  • Input Voltage
  • 24V DC Power Supply
  • Phase
  • Single Phase Compatible
  • Connection Type
  • Removable Terminal Blocks
  • Material
  • Plastic Housing with Electronic Components
  • Backplane Current Draw
  • 70 mA @ 5V DC
  • Storage Temperature
  • -40C to 85C
  • Isolation Voltage
  • 1200V AC (Continuous)
  • Output Current Range
  • 4-20 mA
  • Response Time
  • 3 ms to 63 ms
  • Output Voltage Range
  • 0-10V DC
  • Channels
  • 2 Analog Outputs
  • Resolution
  • 15-Bit
  • Relative Humidity
  • 5% to 95%, Non-condensing
  • Module Type
  • CompactLogix/ MicroLogix 1500 I/O Analog Output


ALLEN-BRADLEY 1769-0F2 Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Payment Terms
  • Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T)
  • Supply Ability
  • 100 Pieces Per Day
  • Delivery Time
  • 1 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • AS PER CAUSTOMER
  • Main Export Market(s)
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • USED ALLEN-BRADLEY 1769-0F2


About ALLEN-BRADLEY 1769-0F2

USED ALLENBRADLEY 17690F2
ALLENBRADLEY 17690F2

Key specifications
Manufacturer AllenBradley  Rockwell Automation
Product family 1769 Compact IO  CompactLogix
Module type Analog Output
Number of outputs 2 singleended channels
Voltage outputs 10 VDC 010 VDC 05 VDC 15 VDC
Current outputs 020 mA 420 mA
Resolution 14bit 14bit plus sign for bipolar operation
Conversion DeltaSigma
Maximum conversion rate 25 ms for all channels
Bus current 120 mA at 51 VDC
Mounting DIN rail or panel mount
Isolation 510 VAC  720 VDC qualification isolation between output group and bus
Typical applications PLC control of proportional valves VFD speed references positioners analog actuators and processcontrol equipment


Advanced Analog Output Performance

The 1769-0F2 module delivers exceptional analog output precision with 15-bit resolution, supporting both 0-10V DC voltage and 4-20 mA current output ranges. Its fast response times (3 ms to 63 ms) and high output accuracy are essential for precise process control and reliable industrial automation.


Robust Industrial Design

Constructed with a light grey/yellow thermoplastic housing and a compact rectangular form, this module can withstand harsh industrial environments. With an IP20 rating, 1200V AC isolation, overload and short-circuit protection, and a wide operating temperature range (0C to 60C), it promotes reliable, safe operation in varied settings.


Effortless Integration and Maintenance

Designed for DIN rail mounting and compatible with removable terminal blocks, the 1769-0F2 is easy to install and maintain. Status indicators simplify diagnostics, while a compact size ensures it fits neatly into tight control panels. Its compatibility with CompactLogix/MicroLogix PLCs streamlines system integration for both new and existing installations.

FAQ's of ALLEN-BRADLEY 1769-0F2:


Q: How do I install the ALLEN-BRADLEY 1769-0F2 analog output module in a PLC system?

A: Begin by powering down the PLC system. Securely mount the module onto a DIN rail, connect your wiring to the removable terminal blocks using screw terminals, and link the module to the CompactLogix or MicroLogix 1500 controller. Double-check all connections before restoring power.

Q: What output signal types does the 1769-0F2 module support and how can I select between them?

A: The 1769-0F2 provides two output channels, each configurable for 0-10V DC voltage or 4-20 mA current. Output type selection is made via the PLC program or project configuration software during module setup.

Q: When is it beneficial to use the 1769-0F2 module in an automation project?

A: The module is especially advantageous when high-resolution analog outputs are needed to drive actuators or control devices requiring variable voltage or current in industrial automation, process control, or manufacturing systems.

Q: Where can the 1769-0F2 module be utilized within an industrial automation setup?

A: It is suitable for integration into control panels managing industrial machinery, process automation lines, or any PLC-controlled system requiring accurate analog output, specifically with CompactLogix or MicroLogix 1500 PLC platforms.

Q: What are the primary benefits of using the 1769-0F2 module in my control system?

A: Key benefits include high system efficiency, superior output accuracy, quick response times, robust overload and short-circuit protection, simple installation, and flexible compatibility with standard PLC systems.

Q: How does the module ensure operational safety and equipment protection?

A: The 1769-0F2 includes built-in overload and short-circuit protection, 1200V AC isolation, and overheating protection, helping safeguard connected devices and the overall control system.

Q: What is the process for troubleshooting a non-functioning 1769-0F2 module?

A: Start by checking module status indicators for error signals. Verify voltage supply (24V DC), inspect wiring and terminal connections, and ensure the module is correctly programmed in the PLC software. If issues persist, refer to the manufacturer's documentation or seek assistance from authorized service providers.
