MOXA NPORT 5610-8-DT

Name: MOXA NPORT 5610-8-DT
Brand: IK AUTOMATION
Price: 1223.0 INR
Availability: InStock

Price 1223.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MOXA NPORT 5610-8-DT Specification

Surface Finish
Powder Coated

Operating Temperature
0 to 60C

Feature
8-port serial connectivity, Real COM/TTY drivers, easy configuration, surge-protected serial lines

Humidity %
5-95% RH, non-condensing

Shape
Rectangular

Connector Type
DB9 male

Mounting Type
Desktop

IP Rating
IP30

Product Type
Serial Device Server

Application
Industrial networking, serial device connectivity

Protection Level
Surge protection on serial lines

Rated Voltage
12 to 48 VDC, 18 to 30 VAC

Energy Consumption
Max. 355 mA @ 12 VDC

Output Type
RS-232/422/485 Serial Output

Color
Black/Grey

Dimension (L*W*H)
197 x 44 x 125 mm

Weight
1440 g

Input Voltage
12-48 VDC, 18-30 VAC

Size
8-port

Material
Metal (Steel) Housing

Connection Type
DB9 Male and terminal block

Configuration Options
Web/Serial/Telnet/Windows Utility/Serial Console

Management
SNMP, HTTP, DHCP, Telnet, Windows Utility

MTBF
204,967 hrs

Network Interface
10/100 Mbps Ethernet

Flow Control
RTS/CTS, XON/XOFF

Power Connector
Terminal block, Power Jack

Baud Rate
50 bps to 921.6 kbps

Console Port
RS-232 (RJ45) for console

Serial Port Count
8 Ports

Serial Standards
RS-232/422/485, software selectable per port

Storage Temperature
-20 to 85C

LED Indicators
Ready, Ethernet (10/100M), Serial Tx/Rx

About MOXA NPORT 5610-8-DT

Introducing the new release MOXA NPORT 5610-8-DT-an unmatchable paragon of industrial networking and serial device connectivity. Experience instant savings with this featured, unassailable 8-port serial device server, built with sturdy steel housing and advanced surge protection. Supporting RS-232/422/485 standards, seamless 10/100 Mbps Ethernet connectivity, and a wide operating temperature range, this model stands as the industry's benchmark. Equipped with Real COM/TTY drivers, versatile configuration options, and a comprehensive suite of security features, the MOXA NPORT 5610-8-DT is the ultimate solution for industrial tasks, ensuring reliable, efficient integration for networked applications across India.

Unassailable Performance & Versatile Applications

The MOXA NPORT 5610-8-DT offers competitive advantages including robust surge protection, extensive configuration versatility, and unassailable reliability-making it a paragon in industrial networking. Ideally used as a bridge for serial-to-Ethernet integration, it excels in applications like remote device management, factory automation, utility metering, and machine monitoring. Its instant adaptability and dependable architecture enable uninterrupted control and communication, vital for dealers and industrial users seeking optimal performance and connectivity.

Efficiency in Payment & Global Export Reach

Enjoy streamlined arrival and order processing with efficient payment terms tailored for dealers, importers, and wholesalers. The MOXA NPORT 5610-8-DT is available for purchase order and global delivery, reaching main export markets including Asia, the Middle East, and Europe. Expect swift dispatch, precise tracking, and assured lead times to ensure your equipment arrives as planned-making it an optimal choice for seamless industrial integration in diverse markets.

FAQ's of MOXA NPORT 5610-8-DT:

Q: How does the MOXA NPORT 5610-8-DT enhance serial device connectivity in industrial environments?

A: By providing 8 ports with software-selectable RS-232/422/485 standards, the device enables seamless integration of multiple serial devices into Ethernet networks, ensuring reliable and scalable connectivity for industrial applications.

Q: What configuration options are available for the MOXA NPORT 5610-8-DT?

A: Configuration can be performed via web interface, serial port, Telnet, Windows Utility, or the serial console, offering flexible management tailored to user preferences and installation setups.

Q: Where can the MOXA NPORT 5610-8-DT be used effectively?

A: This device excels in industrial networking, remote equipment control, factory automation, utility monitoring, and any application requiring secure and stable serial-to-Ethernet communication.

Q: What are the key benefits of using Real COM/TTY drivers with this device?

A: Real COM/TTY drivers allow seamless integration with Windows and Linux systems, enabling serial devices to appear as local COM or TTY ports for hassle-free application compatibility and streamlined operations.

Q: How is surge protection implemented in the MOXA NPORT 5610-8-DT?

A: Surge protection is built into the serial lines, safeguarding connected devices against electrical disturbances and ensuring system integrity in demanding industrial settings.

Q: What is the typical delivery time after placing a purchase order for the MOXA NPORT 5610-8-DT?

A: Delivery times depend on the export market and stock availability but are typically managed to ensure prompt arrival and reliable order fulfillment for clients worldwide.
