NATIONAL INSTRUMENTS NI 9472

Price 1212 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

NATIONAL INSTRUMENTS NI 9472 Specification

Overheating Protection
Built-in Safeguards for Overload/Short-circuit

Surface Finish
Matte

Connector Type
Spring Terminal, 10-position

Mounting Type
DIN Rail Mount, C Series Chassis

Feature
Hot-swappable, C Series Module, High Current Output

IP Rating
IP20

Shape
Rectangular

Humidity %
5 % to 95 % RH, non-condensing

Operating Temperature
-40 C to 70 C

Efficiency
High Output Efficiency

Insulation Material
Plastic (Polymer) Enclosure

Power Factor
N/A (Digital Output)

Product Type
Digital Output Module

Application
Industrial Automation, Data Acquisition, Control Systems

Protection Level
Digital Isolation up to 60VDC, Overvoltage Protection

Frequency (MHz)
N/A (DC Signals)

Rated Voltage
6 VDC to 30 VDC

Energy Consumption
Max 4.5 W (Module Only)

Output Type
Sinking/Sourcing (Configurable)

Color
Gray (with Colored Label)

Dimension (L*W*H)
90 x 37 x 88 mm

Weight
154 g

Phase
Single Phase (DC Output)

Size
Compact Module

Input Voltage
N/A (Output Module)

No Of Poles
8 Channels (Digital Output)

Material
Plastic Housing with Metal Inserts

Connection Type
Spring Terminal Block

Storage Temperature
-40 C to 85 C

Channel-to-Channel Isolation
No; common ground

Maximum Output Delay
< 500 microseconds

Vibration/Shock Resistance
IEC 60068-2-27/IEC 60068-2-6

Maximum Update Rate
1 kHz typical

LED Indicators
Per Channel Output Status

Channels
8 Digital Output Channels

Hot Swap Support
Yes (C Series)

NI Model Number
NI 9472

Compatible Chassis
NI CompactDAQ, CompactRIO

Output Current per Channel
Up to 500 mA Continuous

Safety Standards
CE, C-UL, UL, RoHS Compliant

Isolation Voltage
60 VDC Channel-to-Earth Isolation

NATIONAL INSTRUMENTS NI 9472 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
USED NATIONAL INSTRUMENTS NI 9472

About NATIONAL INSTRUMENTS NI 9472

Experience the latest in digital output innovation with the NATIONAL INSTRUMENTS NI 9472. This grand C Series module features 8 outstanding digital output channels, each supporting up to 500 mA continuous output with robust overvoltage and overheating protection. Utilise the offer to redeem this triumphant industrial solution, ideal for automation, data acquisition, and control systems. Experience high output efficiency with hot-swap support, LED indicators, and swift output status updates. Compatible with NI CompactDAQ and CompactRIO, this compact, rugged module ensures durable performance in demanding environments. Outstanding safety standards and reliable isolation guarantee peace of mind.

Versatile Industrial Applications

The NATIONAL INSTRUMENTS NI 9472 stands out in various application areas, including industrial automation, factory control systems, and remote data acquisition. Commercially, it excels in process management, machine integration, and system control tasks. The module's reliable digital outputs and robust design make it ideal for manufacturing floors, research facilities, energy management, and panel assembly. Its compatibility with CompactDAQ and CompactRIO platforms extends its utility to diverse environments, ensuring seamless deployment wherever complex automation challenges arise.

Secure Packaging & Prompt Delivery

All NI 9472 modules are expertly packaged in high-grade protective material to safeguard against transit damage, ensuring the shipment arrives in pristine condition. The FOB port is located in Germany, providing efficient global dispatch processes. Average proposal amounts are calculated to guarantee the lowest expenditure possible. Delivery times are streamlined, typically ranging from 2 to 4 weeks based on order volume and location. Commercial buyers benefit from reliable, transparent logistics and competitive pricing that ensure maximum value.

FAQ's of NATIONAL INSTRUMENTS NI 9472:

Q: How can I utilise the NI 9472 for industrial automation?

A: You can integrate the NI 9472 into automation systems using NI CompactDAQ or CompactRIO chassis, enabling digital control of devices with up to 500 mA output per channel, making it ideal for controlling relays, solenoids, or actuators.

Q: What are the benefits of the module's outstanding isolation and protection features?

A: The NI 9472 provides up to 60 VDC channel-to-earth isolation and has built-in overvoltage and overheating protection, ensuring both operator safety and long-term module reliability in demanding environments.

Q: Where can the NI 9472 be deployed for maximum commercial impact?

A: The module is best utilised in manufacturing plants, research labs, and automation control rooms, delivering grand performance for data acquisition, machine control, and robust digital output solutions.

Q: What is the process for redeeming offers or discounts for the NI 9472?

A: Contact your authorised distributor, dealer, or supplier with your requirements to learn about current offers. They will guide you through the process of redeeming any available discounts and securing the most competitive pricing.

Q: How is the NI 9472 packaging designed to ensure safe delivery?

A: Each unit is securely packed with protective insulation and robust exterior packaging to prevent damage during shipment, guaranteeing that your product arrives in outstanding condition.
