Omron CP1H-X40DT-D CP1H CPU Unit

Price 10000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Omron CP1H-X40DT-D CP1H CPU Unit Specification

Features
High-speed counters, pulse output, expansion capability, built-in analog and serial communication

IP Rating
IP20

Usage & Applications
Industrial automation, machine control

Protection Level
IP20

Frequency
50 Hertz (HZ)

Display
LED indicators

Output
16 transistor outputs (sinking/sourcing, NPN/PNP)

Mounting Type
DIN rail or direct mounting

Installation Type
DIN rail/mounting plate

Current
0.8A (5V DC internal) / 0.4A (24V DC external)

Connectivity Type
RS-232C, USB, Option Board

Phase
Single Phase

Product Type
CPU Unit

Operating Temperature
0 to 55C

Working Temperature
0 to 55C

Input
24 DC inputs (sink/source)

Application
Industrial

Supply Voltage
220 Volt (v)

Dimension (L*W*H)
130 x 100 x 85 mm

Weight
Approximately 610 g

Warranty
1 Month

Analog Input
Built-in (model dependent), expansion possible

Power Consumption
32 W max

Program Capacity
20K steps

Communication Ports
USB, RS-232C, and optional boards (e.g., Ethernet, RS-485)

Number of I/O Points
40 (24 inputs, 16 outputs)

Built-in Real Time Clock
Yes

Expansion Units
Up to 7 expansion units supported

Pulse Output
4 axes, 100 kHz

Shock Resistance
IEC 60068-2-27, 147 m/s², 3 times each in X, Y, and Z directions

Vibration Resistance
IEC 60068-2-6, 5 to 8.4 Hz (amplitude: 3.5 mm), 8.4 to 150 Hz (acceleration: 9.8 m/s²)

Programmable Language
Ladder, Structured Text (via software)

High-speed Counter
4 channels, 100 kHz

Data Memory
10K words

Omron CP1H-X40DT-D CP1H CPU Unit Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID), Cheque

Supply Ability
100 Units Per Month

Delivery Time
2-3 Days

Main Domestic Market
All India

About Omron CP1H-X40DT-D CP1H CPU Unit

We are a noteworthy manufacturer of Omron CP1H-X40DT-D CP1H CPU Unit in the market. This is made using utmost grade raw material and sophisticated machinery at our unit as per the industrial set standards and norms. Omron CP1H-X40DT-D CP1H CPU Unit is thoroughly tested on diverse parameters to make sure that we serve a defect free range to our customers.

Versatile and Expandable Control Platform

The CP1H-X40DT-D offers seamless integration in industrial automation environments, supporting up to seven expansion units and various communication protocols. Its design ensures flexibility, allowing users to accommodate future system growth or modifications easily. DIN rail or direct mounting options provide practical installation solutions in diverse industrial settings.

Enhanced Performance and Reliability

With high-speed pulse output and counters (4 axes at 100 kHz), this unit excels in precise machine control and positioning. Vibration and shock resistance according to IEC standards guarantee dependable operation in harsh conditions, while the built-in real-time clock and sturdy IP20 casing further boost reliability for extended operation.

Comprehensive Connectivity

USB and RS-232C ports offer immediate programming access, while optional expansion communication boards extend connectivity to Ethernet or RS-485. The built-in analog input (model dependent) and expansion possibilities support a broad range of industrial devices and sensors, ensuring compatibility with numerous automation systems.

FAQ's of Omron CP1H-X40DT-D CP1H CPU Unit:

Q: How can I connect the Omron CP1H-X40DT-D to external devices or networks?

A: This CPU unit comes equipped with USB and RS-232C ports for direct programming and device connection. You can further extend communication capabilities with option boards, such as Ethernet or RS-485, for integrating various industrial networks and peripherals.

Q: What is the process for expanding the system's I/O capabilities?

A: You can connect up to seven Omron expansion units to the CP1H-X40DT-D via dedicated expansion ports. This allows you to increase I/O points, add analog modules, or integrate specialized function units, making it easy to tailor the system for evolving automation needs.

Q: Where is this PLC typically installed, and what mounting options are available?

A: The CP1H-X40DT-D is designed for industrial environments and can be mounted directly onto a DIN rail or a mounting plate. Its compact size and rugged construction suit a variety of control panels and machinery enclosures across manufacturing and process industries.

Q: What programming languages and software are used for the CP1H-X40DT-D?

A: This controller supports programming in Ladder Diagram and Structured Text (using Omron's CX-Programmer software or other compatible programming tools). This flexibility enables users to select the language best suited to their application and experience.

Q: When should I consider using the analog input capabilities of this unit?

A: You should utilize the built-in or expansion analog input for applications that require precise measurement and control of variables such as temperature, pressure, or flow. This is especially valuable in process automation or when integrating sensors that output analog signals.

Q: What benefits does the high-speed counter and pulse output provide?

A: The built-in 4-channel high-speed counter and 4-axis, 100 kHz pulse output enable precise control over positioning tasks, stepper motor driving, and rapid monitoring of encoder signals. These capabilities are essential for applications like packaging machinery or assembly automation, where accuracy and speed are crucial.

Q: How does the CP1H-X40DT-D ensure reliable operation under industrial conditions?

A: The unit meets IEC standards for vibration and shock resistance, operates within a temperature range of 0 to 55C, and is protected by an IP20 casing. These features, along with LED status indicators, contribute to continuous and robust performance in challenging industrial settings.
