OMRON CP1H-Y20DT-D

Price 5000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

OMRON CP1H-Y20DT-D Specification

Mounting Type
DIN Rail Mounting

Surface Finish
Matte

IP Rating
IP20

Efficiency
High

Insulation Material
Flame-retardant Polymer

Feature
High-speed Counter, Pulse Output, Expandable via Option Boards

Operating Temperature
0C to 55C

Connector Type
Screw Type

Overheating Protection
YES

Shape
Rectangular

Humidity %
10% to 90% RH (non-condensing)

Product Type
Programmable Logic Controller (PLC)

Application
Industrial Automation

Protection Level
IEC IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
AC 100-240V

Energy Consumption
30 VA max.

Output Type
Transistor (Sink/Source)

Color
Grey

Dimension (L*W*H)
130 x 100 x 85 mm

Weight
Approx. 600 g

Phase
Single Phase

Input Voltage
DC 24V

Size
Compact

Connection Type
Screw Terminal Blocks

Material
Plastic, Metal

High Speed Counter Input
100 kHz, 4 channels

Output Contact Type
Transistor (NPN/PNP)

Communication Ports
RS-232C, USB

Program Capacity
20K steps

Storage Temperature
-20°C to 75°C

Sampling Period
1 ms (minimum)

Input Points
12 Digital Inputs

Expansion Capability
Supports up to 2 option boards

Output Points
8 Digital Outputs

Surge Withstand Voltage
1500V AC (1 min)

Data Memory
8K words

Standards Compliance
CE, cULus

Clock/Calendar
Built-in (Battery Backed-up)

Isolation
Photocoupler (Input/Output)

Vibration Resistance
10 to 57 Hz, 0.075 mm double amplitude

Pulse Output
100 kHz, 4 axes maximum

OMRON CP1H-Y20DT-D Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal, Letter of Credit at Sight (Sight L/C), Cheque, Letter of Credit (L/C), Western Union, Delivery Point (DP), Cash Advance (CA), Telegraphic Transfer (T/T), Days after Acceptance (DA), Cash in Advance (CID)

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Australia, Central America, South America, Western Europe, Middle East, Eastern Europe, Asia, North America, Africa

Main Domestic Market
All India

Certifications
OMRON CP1H-Y20DT-D

About OMRON CP1H-Y20DT-D

Ending Soon-avail the spectacular value of the OMRON CP1H-Y20DT-D PLC, designed for dominant performance in industrial automation. With 12 digital inputs and 8 output points (transistor NPN/PNP), this compact yet meritorious controller excels with high-speed counter inputs and pulse output capabilities (up to 100 kHz, 4 axes). Enjoy the latest program capacity of 20K steps with built-in clock/calendar and robust memory. Supporting two option boards for expansion, this industrial-grade unit meets CE and cULus standards and boasts durable, flame-retardant construction for long-term reliability. Secure your upgrade before stock runs out!

Surface of Application & Specific Usage Guidelines

The OMRON CP1H-Y20DT-D is engineered for industrial automation environments-ideal for conveyor control, robotics, and production line management. Its robust nature allows use in harsh conditions, with operating temperatures ranging from 0C to 55C and humidity tolerance of 10% to 90% RH. To use, simply mount on a DIN rail, connect via screw terminal blocks, then leverage its high-speed counter and pulse output features for precise, high-efficiency machine control.

Global Supply, Certifications & Payment Flexibility

Stock ready and instantly shipped to main export markets including China, the OMRON CP1H-Y20DT-D comes certified under CE and cULus standards. Our streamlined supply chain ensures prompt delivery to dealers, distributors, importers, and wholesalers. Payment terms are flexible for your convenience, accommodating various business needs. Trust in our certified product with rapid global dispatch for your automation solutions.

FAQ's of OMRON CP1H-Y20DT-D:

Q: How can I expand the OMRON CP1H-Y20DT-D for additional automation tasks?

A: You can easily expand the OMRON CP1H-Y20DT-D by adding up to two option boards, enabling greater flexibility and the ability to handle extra input/output or communication functions.

Q: What industries most benefit from using the CP1H-Y20DT-D?

A: Industries engaged in industrial automation, such as manufacturing, robotics, and process control, are best suited for the CP1H-Y20DT-D given its high-speed processing, flexibility, and reliable performance.

Q: When can I expect CP1H-Y20DT-D units to ship if I place an order?

A: Units are typically in stock and ready to be shipped immediately upon order confirmation thanks to our robust supply chains serving both domestic and international markets.

Q: Where should the CP1H-Y20DT-D be installed for optimal performance?

A: Install the PLC in a well-ventilated control cabinet on a DIN rail, ensuring ambient temperatures remain within the 0C to 55C range for optimal reliability and longevity.

Q: What are the main benefits of the CP1H-Y20DT-D's high-speed counter and pulse output?

A: Its high-speed counter (100 kHz, 4 channels) and pulse output (up to 100 kHz) enable precise control and coordination of advanced automation tasks such as robotic arms, conveyor systems, and stepper motor drives.
