PHOENIX CONTACT CBMC E4

Price 1333 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

PHOENIX CONTACT CBMC E4 Specification

Efficiency
-

IP Rating
IP20

Insulation Material
Polyamide

Shape
Rectangular

Power Factor
-

Feature
Adjustable, electronic current monitoring, resettable

Connector Type
Push-in / Screw terminal

Overheating Protection
Yes, electronic

Humidity %
93% (non-condensing)

Surface Finish
Matte

Operating Temperature
-25C to +60C

Mounting Type
DIN rail

Product Type
Electronic Circuit Breaker

Application
Industrial automation, power distribution

Protection Level
Electronic protection for 4 channels

Frequency (MHz)
50/60 Hz

Rated Voltage
24 V DC

Energy Consumption
-

Output Type
DC output, 4-channel

Color
Grey

Dimension (L*W*H)
41 mm x 99 mm x 80 mm

Weight
130 g

Input Voltage
24 V DC

Size
Compact

Phase
Single phase

Material
Polyamide (PA) / Plastic housing

No Of Poles
4

Connection Type
Screw terminal

Response time
< 5 ms (typically)

Voltage drop
< 150 mV

Breaking capacity
Up to 10 kA at 24 V DC

Environmental protection
RoHS compliant

Signal output
Remote signalization via collective signal contact

Standards compliance
IEC/EN 60934, UL 2367

Current setting range per channel
1 A to 10 A

Number of channels
4 (individually adjustable)

Trigger type
Electronic with adjustable current threshold

Signaling
LED status indicators per channel

PHOENIX CONTACT CBMC E4 Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
USED PHOENIX CONTACT CBMC E4

About PHOENIX CONTACT CBMC E4

Order the PHOENIX CONTACT CBMC E4, engineered for optimum performance in industrial automation and power distribution. Explore enhanced safety with its potent 4-channel electronic protection, each channel featuring individually adjustable current settings from 1A to 10A. Instant checkout available for this compact grey device, boasting IP20 rating, quick response times under 5ms, and remote signalization via collective contact. Its status LEDs, resettable functions, and robust polyamide housing ensure consistent, best-in-class DC output protection conforming to IEC/EN and UL standards. Ideal for DIN rail mounting, the CBMC E4 guarantees reliable operation within -25C to +60C.

Distinguishing Features and Competitive Edge

The PHOENIX CONTACT CBMC E4 stands out with its adjustable electronic current monitoring and compact, resettable four-channel design. Competitive advantages include rapid response times, potent overload protection, and LED indicators for clear channel status. Direction of use is straightforward: mount on DIN rail, connect via push-in or screw terminals, and adjust individual channels as required. German engineering ensures durability, while RoHS compliance underlines its environmental responsibility, making it a preferred choice for distributors and end-users alike.

Order Fulfillment, Sample Policy & Export Markets

Order completion is prompt, with detailed quotations available upon request. Sample policies are flexible-connect with us to discuss your trial expenditure and secure pre-purchase samples. Our supply ability accommodates bulk demands, making us a reliable partner for global projects. PHOENIX CONTACT CBMC E4 is actively exported to diverse markets, including Europe, Asia, and the Americas, meeting the needs of manufacturers, wholesalers, and industrial service providers worldwide.

FAQ's of PHOENIX CONTACT CBMC E4:

Q: How can I adjust the current threshold on each channel of the CBMC E4?

A: The CBMC E4 provides simple adjustment of the current threshold per channel via accessible controls on the device itself, allowing precise calibration from 1A to 10A as needed for your application.

Q: What benefits does electronic protection offer compared to traditional circuit breakers?

A: Electronic protection, as used in the CBMC E4, offers faster response times (<5 ms), greater precision, remote status monitoring, and easy reset functionality, providing more reliable and potent circuit safeguarding than traditional breakers.

Q: Where is the CBMC E4 typically used?

A: This unit is ideal for industrial automation and power distribution systems, providing optimum multi-channel protection for DC loads in demanding environments such as manufacturing plants, control panels, and process industries.

Q: What is the process for ordering samples of the PHOENIX CONTACT CBMC E4?

A: You can request samples by contacting our sales team, who will guide you through the quotation process and inform you about sample availability and related expenditure.

Q: When should I use the resettable function on the CBMC E4?

A: Activate the resettable function after resolving a fault or overload situation to restore protection and resume normal operation, ensuring continued safety and system uptime.

Q: How does the LED signaling feature enhance device usage?

A: Each channel of the CBMC E4 features a dedicated LED status indicator, enabling users to promptly identify channel status or triggered protection, streamlining diagnostics and maintenance.
