REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW

Send Inquiry

Request To Call Back

REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW

Get a Price/Quote

MOQ : 1 Piece

REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW Specification

Operating Temperature
0C to +40C

Mounting Type
Panel/Control Cabinet Mount

Surface Finish
Powder Coated

Efficiency
>= 96%

Feature
Integrated safety, High performance, Modular design

IP Rating
IP20

Overheating Protection
Integrated thermal protection with diagnostics

Connector Type
Plug and Screw Terminals

Power Factor
>= 0.95

Humidity %
Max. 90% (non-condensing)

Insulation Material
Polyamide/Polyester

Shape
Rectangular

Product Type
Drive Controller

Application
Automation, motion control, machinery drive control

Protection Level
IP20

Frequency (MHz)
0-400 Hz

Rated Voltage
3 x AC 230-480 V

Energy Consumption
Less than 20 W (typical standby)

Output Type
PWM, Digital Output

Color
Grey

Dimension (L*W*H)
280 x 65 x 210 mm

Weight
2.4 kg

Phase
Three Phase

Size
Standard Modular

Input Voltage
3 x AC 230-480 V

Connection Type
Screw terminal, Plug-in connectors

Material
Metal housing with plastic components

No Of Poles
3

Motor Type Supported
Synchronous and asynchronous motors

Cooling Method
Natural convection

Control System
Fieldbus support (Ethernet, PROFIBUS, CANopen, SERCOS III)

Commutation
Digital, encoder feedback supported

Brake Chopper
Integrated

Minimum Load Inductance
2.5 mH

Rated Current
9 A

Standards Compliance
EN 61800-5-1, IEC standards

Firmware
Pre-installed, upgradable

Display
Status LEDs, parameter/data display via interface

Model Number
HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW

Series
IndraDrive Cs

Software Compatibility
IndraWorks, standard engineering tools

Safety Function
STO (Safe Torque Off)

REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW

About REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW

Last Chance to own the illustrious REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW at a stellar Sale price! Enlightened engineering meets seamless motion control in this state-of-the-art IndraDrive Cs series drive, trusted by professionals worldwide. Add to Cart and enhance your automation setup with a standout 9 A rated current, digital commutation, integrated safety and diagnostics, and versatile fieldbus support (Ethernet, PROFIBUS, CANopen, SERCOS III). Supporting both synchronous and asynchronous motors, it features natural convection cooling, integrated brake chopper, and a modular, panel-mount design. Certified to EN 61800-5-1/IEC standards, this drive offers outstanding performance, energy efficiency, and robust IP20 protection for industrial excellence.

Extensive Features & Diverse Application Media

The REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW boasts features such as integrated Safe Torque Off, high-efficiency operation (>= 96%), and advanced digital encoder feedback. With broad application mediaautomation, motion control, and machinery drive controlthis drive is ideally suited for use in demanding industrial environments. Built with a powder-coated metal body and IP20 protection, it assures reliable, long-lasting performance for three-phase machinery. IndraWorks and standard engineering tools ensure seamless system compatibility.

Premium Order Processing & Certified Global Dispatch

FOB Port: Germany. We pride ourselves in premium order processing, careful packing & dispatch to ensure every drive leaves in perfect condition. Expected delivery time varies by destination but typically ranges between 1-4 weeks. Each unit is shipped with full certification, guaranteeing compliance with EN and IEC standards. Our commitment to quality means your project benefits from efficient, traceable, and secure logistics every step of the way.

FAQs of REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW:

Q: How does the REXROTH HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW enhance industrial automation systems?

A: The drive delivers precise motion control with stellar efficiency, supporting multiple communication protocols, digital feedback, and built-in safety features, making it an ideal solution for advanced automation and machinery drive applications.

Q: What motor types are supported by this REXROTH model?

A: This unit is compatible with both synchronous and asynchronous motors, offering flexibility across a range of industrial uses.

Q: Where is the primary port of dispatch for this product?

A: Orders are processed and shipped from Germany, ensuring direct access to original Bosch Rexroth quality and certification.

Q: When can customers expect delivery after placing an order?

A: Delivery typically takes between 1 and 4 weeks depending on the destination and selected shipping method, with real-time updates available throughout the process.

Q: What key certifications does the HCS01.1E-W0009-A-02-A-CC-EC-ET-L4-NN-FW meet?

A: This drive is fully compliant with EN 61800-5-1 and IEC standards, ensuring high safety, quality, and reliability for industrial installations.

Q: How does the integrated brake chopper benefit drive control operations?

A: The integrated brake chopper improves system safety and responsiveness by allowing efficient energy dissipation during dynamic braking, protecting both equipment and operators.
