Beckhoff El2809

Price 15000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Beckhoff El2809 Specification

Humidity %
95% (non-condensing)

Operating Temperature
-25C to +60C

Efficiency
High efficiency electronic design

IP Rating
IP20

Overheating Protection
Yes, electronic short-circuit and overload protection

Shape
Rectangular

Insulation Material
Plastic

Mounting Type
DIN rail

Feature
TwinSAFE logic, 16 independent channels, compact design

Connector Type
Push-in spring connection

Surface Finish
Moulded plastic

Product Type
Digital Output Terminal (EL2809)

Application
Distributed automation, switching actuators and indicator lamps

Protection Level
IP20

Frequency (MHz)
DC (no frequency), switching output

Rated Voltage
24 V DC (-15%/+20%)

Energy Consumption
typ. 0.6 W

Output Type
Digital, 16 channels, sourcing (positive switching)

Color
Beige

Dimension (L*W*H)
100 mm x 12 mm x 69 mm

Weight
approx. 70 g

Size
Width: 12 mm

Phase
Single phase

Input Voltage
24 V DC

Material
Plastic enclosure, electronic components

Connection Type
Push-in (spring force) terminals

No Of Poles
16 channels

Wire cross section
0.082.5 mm (AWG 28...14)

Electrical isolation
500 V (between power contacts and electronics)

Storage temperature
-40C to +85C

Channel type
Digital sourcing output (P-type)

Status indication
Channel-wise LEDs

Vibration resistance
in accordance with EN 60068-2-6

Approvals/Certifications
CE, UL, RoHS, cULus

Switching capacity
per channel up to 0.5 A resistive load

Current load
0.5 A per channel (maximum 4 A total per terminal)

Relative humidity
up to 95% (non-condensing)

System bus
EtherCAT

Hot swap capability
Yes

Reaction time
< 1 ms

Type code
EL2809

Beckhoff El2809 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD), Telegraphic Transfer (T/T), Paypal, Letter of Credit (L/C), Western Union, Letter of Credit at Sight (Sight L/C), Delivery Point (DP), Cash Against Delivery (CAD), Days after Acceptance (DA), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Pieces Per Day

Delivery Time
1 Hours

Sample Available
Yes

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Central America, Asia, Africa

Main Domestic Market
All India

Certifications
BECKHOFF EL2809

About Beckhoff El2809

Utilise this peerless offer with the Beckhoff EL2809, an unparalleled solution for distributed automation applications demanding superior performance. The EL2809 digital output terminal boasts 16 independently controlled sourcing channels, each delivering a maximum of 0.5A (total 4A) to actuators and indicator lamps. Its robust 500V electrical isolation, hot swap capability, and rapid <1 ms reaction time ensure reliability and efficiency in every use. Personalise your automation setup with a compact, DIN-rail mountable design, moulded plastic enclosure, and push-in spring terminals-this bargain is ideal for professionals seeking uncompromising quality and flexibility.

Distinct Advantages & Application Scope

The Beckhoff EL2809 stands out for its high-density, compact form factor and exceptional switching capacity, providing a competitive edge to integrators and manufacturers. Ideally deployed in distributed automation systems, the EL2809 expertly handles switching actuators and indicator lamps in process and machinery control. Its hot swap feature and comprehensive electronic protection enable continuous process operation and minimise downtime, making it indispensable for applications demanding reliability, high performance, and easy maintenance.

Certifications, Payment & Sample Availability

Certified with CE, UL, RoHS, and cULus, the Beckhoff EL2809 assures compliance and safety for global installations. With a competitive list price, we support flexible payment terms to fit your procurement process and ensure supply continuity. Enjoy quick dispatch across India, ensuring timely delivery for urgent projects. For first-time users or bulk buyers, product samples are readily available, allowing you to experience the EL2809's unmatched quality firsthand before committing to larger orders.

FAQ's of Beckhoff El2809:

Q: How does the Beckhoff EL2809 provide electrical isolation and protection?

A: The EL2809 features 500 V separation between power contacts and electronics, alongside electronic protection against overheating, short-circuit, and overload, ensuring device and system safety.

Q: What specific applications suit the EL2809 terminal best?

A: This terminal is perfect for distributed automation, particularly for controlling actuators and indicator lamps in machinery, offering reliable digital switching in compact environments.

Q: When should I consider using the hot swap capability of the EL2809?

A: Utilise the hot swap feature when replacing or upgrading modules during operations, as it allows adding or removing the terminal without shutting down the control system.

Q: Where can I install the Beckhoff EL2809?

A: The module is designed for easy mounting on DIN rails in control panels or automation cabinets, meeting the needs of manufacturers, integrators, and service providers.

Q: What are the payment and delivery options available for purchasing this product?

A: We offer various payment terms and quick dispatch options to ensure prompt supply to dealers, distributors, and end-users throughout India.

Q: How can I obtain a sample of the Beckhoff EL2809 before making a bulk order?

A: Product samples can be requested through our authorized distributors or sales representatives, enabling you to test and evaluate before larger commitments.
