HOHNER 11-1163X-5000-SN18

Get a Price/Quote

MOQ : 1 Piece

HOHNER 11-1163X-5000-SN18 Specification

Insulation Material
High-grade Polymer

IP Rating
IP67

Feature
Rugged Design, High Precision, Compact Size

Connector Type
M12 Connector

Operating Temperature
-20C to +85C

Surface Finish
Anodized

Mounting Type
Flange Mount

Overheating Protection
YES

Humidity %
95% max (non-condensing)

Shape
Rectangular

Product Type
Incremental Encoder

Application
Industrial Automation, Motion Control

Protection Level
IP67

Rated Voltage
10-30 VDC

Energy Consumption
<1 W

Output Type
Push-Pull or Line Driver

Color
Silver/Black

Dimension (L*W*H)
58 mm diameter, 36 mm length

Weight
210 g

Input Voltage
10-30 VDC

Size
58 mm housing

Phase
Single Phase

No Of Poles
1

Connection Type
Cable with connector

Material
Aluminium Alloy

HOHNER 11-1163X-5000-SN18 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
HOHNER 11-1163X-5000-SN18

About HOHNER 11-1163X-5000-SN18

Buy the renowned HOHNER 11-1163X-5000-SN18an ineffable masterpiece in industrial automation and motion control. Select this high precision rotary encoder with an IP67 protection level and compact rectangular shape, crafted from anodized aluminium alloy. With a reduced price for a limited period, this unit features a 10 mm shaft diameter, 5000 PPR, max rotation of 6000 rpm, and superior shock/vibration resistance. Enjoy flexible output options (Push-Pull or Line Driver) and the reliability of overheating protection, all in a rugged 58 mm housing. Germanys engineering excellence, now available to dealers, distributors, and more.

HOHNER 11-1163X-5000-SN18: Features & Industrial Applications

Engineered for versatility and reliability, the HOHNER 11-1163X-5000-SN18 excels in industrial automation and motion control systems. Its rugged, compact anodized aluminium housing ensures robust performance in challenging environments. With high precision 5000 PPR, IP67 protection, and an M12 connector, installation is straightforward via flange mount. Applications include robotics, conveyor systems, and various motion control setups, benefiting from its single-phase output channels and durable operation across a wide temperature range.

Sample Policy, Export Markets & Transportation Estimate

Samples of the HOHNER 11-1163X-5000-SN18 are provided upon approved request, with expenditures applying as per the companys sample policy. This product is exported worldwide, with major markets including Europe, Asia, and the Americas. FOB Port options are available, and accurate transportation estimates can be provided upon inquiry. Dealers, distributors, and retailers can contact for streamlined import/export logistics and detailed packaging methods to ensure safe delivery.

FAQs of HOHNER 11-1163X-5000-SN18:

Q: How does the HOHNER 11-1163X-5000-SN18 benefit industrial automation systems?

A: Its high pulse rate, rugged design, and accuracy ensure reliable feedback for motion control, enhancing system efficiency and stability in demanding environments.

Q: What are the key features of the HOHNER 11-1163X-5000-SN18 encoder?

A: Key features include a 5000 pulses per revolution (PPR) output, IP67 protection, compact aluminium housing, shock/vibration resistance, flange mounting, and compatibility with both Push-Pull and Line Driver outputs.

Q: Where can the HOHNER 11-1163X-5000-SN18 be used?

A: It is ideal for use in industrial automation, robotics, conveyors, motion control systems, and environments demanding high precision and durability.

Q: What is the process to select the correct output type for my system?

A: Determine your systems requirementschoose Push-Pull for standard compatibility, or Line Driver for long cable runs or improved noise immunity. Consult technical documentation if unsure.

Q: When can I expect delivery and transportation details?

A: Delivery and transportation estimates depend on your location, order quantity, and selected FOB port. Contact the supplier for a specific estimate and shipping schedule tailored to your order.

Q: How can I request a sample of the HOHNER 11-1163X-5000-SN18?

A: Samples are available to qualified requestors; contact the sales team with details of your application and company to initiate the approval and expenditure process.
