MEAN WELL SDR-480P-48

Name: MEAN WELL SDR-480P-48
Brand: IK AUTOMATION
Price: 1346 INR
Availability: InStock

Price 1346 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MEAN WELL SDR-480P-48 Specification

Humidity %
20% to 95% RH (Non-Condensing)

IP Rating
IP20

Surface Finish
Powder Coated

Mounting Type
DIN Rail Mount

Feature
High Efficiency, Narrow Width, Built-in Power Boost

Connector Type
Screw Terminal Blocks

Operating Temperature
-25C to +70C Celsius (oC)

Efficiency
94%

Shape
Rectangular

Overheating Protection
YES

Insulation Material
Plastic/Metal Composite

Power Factor
>0.95 at 230VAC

Product Type
DIN Rail Power Supply

Application
Industrial Automation, Control Systems, Machinery

Protection Level
Overvoltage, Overload, Short Circuit, Over Temperature

Frequency (MHz)
47-63Hz Hertz (HZ)

Rated Voltage
48V DC Volt (V)

Output Type
Single Output

Color
Silver/Gray

Dimension (L*W*H)
85.5 x 125.2 x 128.5 mm Millimeter (mm)

Weight
1.5 kg Kilograms (kg)

Phase
Single Phase

Input Voltage
180~264V AC, 254~370V DC Volt (V)

Size
Compact

Connection Type
Screw Terminal

No Of Poles
Single

Material
Metal (Aluminum Enclosure)

Model Number
SDR-480P-48

EMC Standard Compliance
EN61000-6-2, EN61000-6-4

Ripple & Noise (max)
150mVp-p

DC Output Adjustment Range
48~56V DC

Safety Standard
EN62368-1

Load Regulation
1.0%

Wire Size Range
AWG 16-10

Vibration Resistance
10~500Hz, 2G, 10min./1 cycle, period for 60 min each along X, Y, Z axes

Cooling Method
Free Air Convection

Peak Current
10A Boost Mode (up to 4s)

Altitude Operation
<5000m

Line Regulation
0.5%

Isolation Voltage
4kV AC (input to output)

Hold-up Time
>22ms (at full load, 230VAC)

Standard Output Current
10A

Signal Output
DC OK Relay Contact

Case Material
Aluminum

Parallel Operation
Up to 2 Units

Startup Time
<1s at 230VAC

MEAN WELL SDR-480P-48 Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CUSTOMER

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
USED MEAN WELL SDR-480P-48

About MEAN WELL SDR-480P-48

Ending soon - our exclusive promotion on the MEAN WELL SDR-480P-48, an ineffable laureate in industrial power solutions. This compact, champion-grade single-phase power supply is engineered with a DC output adjustment range of 48~56V, a remarkable 10A boost mode, and 94% efficiency. With robust protections (overvoltage, overload, short circuit, over temperature) and EMC compliance, this aluminum-encased bargain boasts parallel operation, advanced vibration resistance, and quick start-up. The SDR-480P-48 is tailored for control systems, automation, and machinery-reliable performance from Taiwan's renowned craftsmanship.

MEAN WELL SDR-480P-48: Key Features and Distinct Advantages

The MEAN WELL SDR-480P-48 features a high-efficiency design with up to 480W output, a broad voltage adjustment range, and a built-in power boost for demanding industrial applications. Notably compact, its narrow width and powder-coated aluminum enclosure ensure efficient DIN rail mounting. This unit offers silent cooling by free air convection and robust signal output via DC OK relay contact, satisfying stringent international safety and EMC requirements. Advanced protection circuits ensure safe and efficient operation even under challenging conditions.

Sample Policy, Packaging, and Supply Details for MEAN WELL SDR-480P-48

For the MEAN WELL SDR-480P-48, samples can be delivered through reliable transport services, packaged securely to prevent any damage during transit. With our offer, we ensure prompt delivery and professional support for every order. Our supply ability is backed by a consistent inventory, catering to dealers, distributors, importers, exporters, and more. Exceptional packaging details maintain product integrity, ensuring the highest standards from manufacturing in Taiwan to delivery at your site.

FAQ's of MEAN WELL SDR-480P-48:

Q: How does the MEAN WELL SDR-480P-48 support parallel operation?

A: The SDR-480P-48 is designed to allow parallel operation of up to two units, making it suitable for applications that require increased power redundancy or load sharing in industrial automation and control systems.

Q: What safety features are included in the MEAN WELL SDR-480P-48?

A: Safety is paramount with this model. It provides overvoltage, overload, short circuit, and over temperature protection, meeting the EN62368-1 safety standard and delivering reliable performance in demanding environments.

Q: Where can the MEAN WELL SDR-480P-48 be installed and used?

A: Optimally suited for industrial automation, machinery, and control systems, the unit's compact design and DIN rail mount facilitate installation in various industrial settings where robust, consistent DC power is necessary.

Q: What is the process for adjusting the DC output range on this model?

A: The SDR-480P-48 allows for easy DC output voltage adjustment between 48V and 56V, typically done via an onboard potentiometer accessible once the enclosure is opened, allowing precise calibration for your application.

Q: What are the key benefits of choosing the MEAN WELL SDR-480P-48?

A: Users benefit from high efficiency (up to 94%), excellent hold-up time, reliable signal monitoring through DC OK relay, quick startup, and a rugged build that ensures longevity, stability, and safety for mission-critical industrial tasks.
