PHOENIX CONTACT PSR-SCP- 24DC/ESP4/2X1/1X2

Send Inquiry

Request To Call Back

PHOENIX CONTACT PSR-SCP- 24DC/ESP4/2X1/1X2

Name: PHOENIX CONTACT PSR-SCP- 24DC/ESP4/2X1/1X2
Brand: IK AUTOMATION
Price: 1155.0 INR
Availability: InStock

Price 1155.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

PHOENIX CONTACT PSR-SCP- 24DC/ESP4/2X1/1X2 Specification

Efficiency
High response reliability

IP Rating
IP20

Mounting Type
DIN rail mounting

Connector Type
Screw terminal

Feature
Safe switching and monitoring of circuits; Used for two-hand control systems

Overheating Protection
Yes (internal electronic)

Insulation Material
High-grade industrial polymer

Humidity %
Up to 90% (non-condensing)

Surface Finish
Matte/Industrial finish

Shape
Rectangular

Operating Temperature
-25C to +55C

Product Type
Safety Relay Module

Application
Industrial safety circuit control

Protection Level
SILCL 3 (IEC 62061), Cat. 4/PL e (EN ISO 13849-1)

Frequency (MHz)
DC operation; Not applicable

Rated Voltage
24 V DC

Energy Consumption
Approx. 1.8 W

Output Type
2 x N/O, 1 x N/C contacts

Color
Yellow, Grey

Dimension (L*W*H)
99 mm x 22.5 mm x 114.5 mm

Weight
160 g

Size
Standard 22.5 mm housing

Input Voltage
24 V DC

Phase
Single Phase

Material
Plastic, Metal components

No Of Poles
4

Connection Type
Screw terminal connection

Max. Cable Cross Section
2.5 mm2 (solid/stranded)

Response Time
< 20 ms

Release Time
< 25 ms

Test Pulse Tolerance
Compatible with test pulses from controllers

Switching Current
6 A (at 240 V AC)

Contact Material
AgSnO2

Storage Temperature
-40C to +85C

Housing Material
Polyamide plastic

Vibration Resistance
5g (10-150 Hz)

Standards
IEC 61508, EN ISO 13849-1, EN 60947-5-1

Switching Voltage
250 V AC / 24 V DC (max)

About PHOENIX CONTACT PSR-SCP- 24DC/ESP4/2X1/1X2

Experience the sizzling performance of the PHOENIX CONTACT PSR-SCP-24DC/ESP4/2X1/1X2, a blue-ribbon safety relay designed for kingly industrial safety circuit control. Boasting an excellent 6 A switching current at 240 V AC, and rapid response times under 20 ms, this highly recommended solution ensures seamless, safe switching and monitoring of circuits. With best price offers for dealers, exporters, and wholesalers in India, its robust polyamide housing and SILCL 3, Cat. 4/PL e certifications guarantee reliable operation in demanding industrial settings. Act swiftly to secure this premium device!

Unmatched Industrial Performance & Versatile Application

The PHOENIX CONTACT PSR-SCP-24DC/ESP4/2X1/1X2 excels in demanding applications such as two-hand control systems and industrial safety circuits. Its highly competitive advantages stem from advanced safety standards (SILCL 3, Cat. 4/PL e) and high response reliability. Adaptable to diverse sectors including manufacturing, automation, and process control, it thrives in tough environments thanks to robust vibration resistance and temperature tolerance. This unit is ideal for industries requiring dependable safety and seamless integration with controllers.

Flexible Policy, Broad Market Reach & Timely Delivery

Sample policies for the PHOENIX CONTACT PSR-SCP-24DC/ESP4/2X1/1X2 are tailored to fit varied customer outlay and specific project valuations. With a main domestic market focus across India, competitive rates are ensured for wholesalers, retailers, and service providers. Prompt delivery times offer efficiency, allowing clients to integrate this safety relay quickly into their operations. This focus on cost-efficiency, favorable terms, and timely support makes acquiring the device straightforward and economical.

FAQ's of PHOENIX CONTACT PSR-SCP- 24DC/ESP4/2X1/1X2:

Q: How does the PHOENIX CONTACT PSR-SCP-24DC/ESP4/2X1/1X2 improve industrial safety?

A: This relay enhances safety by reliably switching and monitoring circuits, particularly in applications like two-hand control systems, and meets strict standards such as SILCL 3 and Cat. 4/PL e.

Q: What are the primary applications for the PHOENIX CONTACT PSR-SCP model?

A: It is mainly used in industrial environments for safety-related circuit control, including manufacturing, automation, and process control systems requiring high protection levels.

Q: Where can the PSR-SCP-24DC/ESP4/2X1/1X2 be sourced in India?

A: The device is available through authorized dealers, exporters, retailers, wholesalers, and service providers across India.

Q: What is the response and release time of this relay?

A: The relay offers a response time of less than 20 ms and a release time under 25 ms for quick and reliable operation.

Q: How does the sample policy and delivery process work for this product?

A: Customers can request samples based on tailored valuation and outlay, with rapid delivery times and competitive rates across the main domestic Indian market.

Q: What benefits do the robust housing and industrial design of the PSR-SCP offer?

A: Its matte-finished polyamide plastic housing and high-grade insulation ensure durability, vibration resistance up to 5g, and secure DIN rail mounting.
